GT 1201
Description
Topcon GT 1201 Specifications –
Display | 4.3″ Color touch TFT WVGA with LED Backlight |
Keyboard | 24 keys with illuminator |
Battery Operation | Up to 4 hours |
Dust / Humidity | IP 65 |
Operating Temperature | -20°C to 50°C |
Prism EDM Range | 6,000 m |
Prism EDM Accuracy | 1mm+2ppm |
Measuring Time | Fine: 0.9 sec Rapid: 0.6 sec Tracking: 0.4 sec |
Wireless Communication | Bluetooth® Class 1 |
Resolving Power | 2.5” |
Magnification | 30x |
Compensation | Liquid 2-axis tilt sensor |
Range | ±6’ |
Overview
Topcon GT – 1001
The GT 1001 robotic total station is a trimmed down, high-performance solution that’s ready to impress today, yet still grow with you into tomorrow. You get the efficiency of a single-operator robotic system, the power of long-range reflectorless measurements, and the ability to perform as a hybrid positioning solution. All in a compact system that’s a third smaller and twice as fast.
UltraSonic technology is the driving force for the GT Series. You can see and hear the difference immediately. The UltraSonic motors are the fastest available in the market – at 180 degrees per second, it’s the smoothest and most accurate prism-tracking available.
- Ultrasonic Direct Drive motors
- 30% smaller and lighter with more functionality
- TSshield™ global service
- Advanced UltraTrac technology
